Spacer bushing wheel axle rear Tomos

Nut M11x1 x 10 SW19 Wheel nut galvanized

Material: Steel · Surface: galvanized (blue) · Nut type: Hexagon nut 1D · Nominal diameter (thread): 11 mm · Drive: External hexagon · Thread type: MF11x1 (fine pitch thread) · Strength class: 8 · Width across flats: 19 mm · Height: 10 mm · Area of application: Standard

NTN 6201 2RS ball bearing 12/32/10

Bearing type: Deep groove ball bearing · Stock number: 6201 · Inner ring width: 10 mm · Manufacturer: NTN · Ball bearing closed: Yes · Dust protection type: 2RS - NBR contact seal on both sides · Bearing clearance: CN (standard) · Bearing cage: Sheet steel cage ball-guided · Ø outside: 32 mm · Ø inside: 12 mm · Width: 10 mm

Axle rear swing arm | Tomos

Material: Steel · Surface: blackened · Surface: galvanized (blue) · Color: black · Thread type: M12x1.75 (standard thread) · Drive: External hexagon · Ø outside: 18 mm · Ø Bearing inside: 18.1 mm · Ø outside: 22 mm · Ø axle: 12 mm · Ø inside: 12.15 mm · Ø External bearing: 22 mm · Total length: 120 mm · Tomos OEM number: 026083 · Tomos OEM number: 209144

Wheel axle M11x1 x 165 rear galvanized | Tomos Quadro

Material: Steel · Surface: galvanized (blue) · Thread type: MF11x1 (fine pitch thread) · Ø shaft: 11.9 mm · Shank length: 117 mm · Thread length: 12 mm · Thread length: 17 mm · Total length: 185 mm · Tomos OEM number: 230515

Wheel axle M12x1.25 x 220 galvanized | Tomos

Manufacturer: Tomos · Material: Steel · Surface: galvanized (blue) · Thread type: MF12x1.25 (fine pitch thread) · Ø shaft: 11.8 mm · Shank length: 188 mm · Thread length: 16 mm · Total length: 220 mm

Spacer bushing 12/20/11.3 rear wheel axle | Tomos

Nominal diameter inside: 12 mm · Manufacturer: Tomos · Ø outside: 20 mm · Ø inside: 12 mm · Total length: 11.35 mm · Tomos OEM number: 222883

Wheel axle M11x1 x 186 mm galvanized | Tomos Classic, Sprint, Fun Sport'R

Manufacturer: Tomos · Material: Steel · Surface: galvanized (blue) · Thread type: MF11x1 (fine pitch thread) · Ø shaft: 11.9 mm · Shank length: 115 mm · Thread length: 30.5 mm · Thread length: 38 mm · Total length: 186 mm · Tomos OEM number: 226086

GPO wheel clamp left & right | Tomos

Manufacturer: GPO · Material: Steel · Surface: galvanized (blue) · Ø inside: 11.6 mm · Tomos OEM number: 209212

NTN 6201 2RS wheel bearing 12/32/10 front & rear | Tomos

Stock number: 6201 · Width: 10 mm · Manufacturer: NTN · Ball bearing closed: Yes · Dust protection type: 2RS - NBR contact seal on both sides · Ø inside: 12 mm · Ø outside: 32 mm · Tomos OEM number: 044225
