Rubber Ø 33 x 34 rear engine mount | Zündapp

Exhaust cigar 28 mm chrome | Puch Maxi S, N / X30 NS, NL

Manufacturer: Made in Portugal · Material: Steel · Surface: chrome-plated · Color: Chrome · Ø outside: 70 mm · Total length: 920 mm · Ø Internal connection: 28 mm · Flame tube attachment: Flange · Mounting type: Stud bolts & nuts · Mounting type: Welded lug · Number of fixing points: 1 pcs · Ø Flame tube outside: 28 mm · Exhaust type: Cigar

Mitas 2.25 x 17" tires MC11 Semi-Slick Whitewall

Manufacturer: Mitas · Tire width: 2.25 " · Tire width [mm]: 57.15 · Width: 2 1/4 " · Color: black · Color: white · Wheel size: 17 " · Old designation: 21 x 2.25 " · Speed index: J = 100 km/h · Load capacity index: 39 = 136 kg · Profile type: MC11 · Tire type: Semi-slick · White wall: Yes · Tubeless (yes/no): Tubetype TT (requires hose)

CIF Clamping screw front brake | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: CIF · Material: Steel · Surface: galvanized (blue) · Area of application: Standard · Ø outside: 11 mm · Thread type: M7x1 (standard thread) · Total length: 25 mm · Drive: External hexagon · Screw head: Hexagon · Number of components: 6 pcs · Thread length: 19.5 mm · Width across flats: 11 mm

Washer under sprocket coaster brake NOS

Manufacturer: Puch · Ø outside: 41 mm · Thickness: 1.7 mm · Ø inside: 35 mm · Nominal diameter (thread): 35 mm

17 mm Bing SRF carburetor (replica)

Nominal diameter: 17 mm · Material: Aluminum · Component group Carburetor: Carburetor complete · Carburetor type: SRF · Choke control: Hand choke · Width: 64 mm · Total length: 78 mm · Nozzle thread: M4x0.7 (standard thread) · Mounting type: Plug connection clamped · Ø fuel hose connection: 6 mm · Ø Air filter connection: 60 mm · Ø Air filter connection: 64 mm · Height: 117 mm · Ø Internal connection: 23 mm · Mixed oil connection: No · Vacuum connection: No · Nozzle block: 2.xx · Clamping screw torque (max.): 3 N/m · Clamping screw torque (max.): 4 N/m · Area of application: Tuning

swiing® revival clutch cover gasket | Zündapp Belmondo (Type 247)

Manufacturer: swiing® revival parts · Material: Sealing paper · Thickness: 0.45 mm · Number of fixing points: 9 pcs · Number of components: 1 pcs

GPO clutch plates 2 pcs. | Zündapp Belmondo

Manufacturer: GPO · Ø inside: 74.5 mm · Ø outside: 103.5 mm · Thickness: 2.9 mm · Number of slats: 2 pcs · Area of application: Standard

RMS V-belt Mono 960 mm (original) | Piaggio Ciao

Manufacturer: RMS · Material: Fabric insert · Material: Rubber · Gearbox type: Mono · Rolling circumference: 960 mm · Outer width: 9.8 mm · Belt profile: untoothed / untoothed · Height: 8.5 mm

EBR fork reinforced black | Sachs / Zündapp Belmondo

Total length: 610 mm · Color: Chrome · Color: black · Manufacturer: EWC · Material: Steel · Surface: chrome-plated · Surface: varnished · Thread type: MF26x1 (fine pitch thread) · Adjustable: No · Spar end distance (center-center): 139 mm · Ø outer head tube: 26.2 mm · Ø head tube inside: 22.1 mm · Ø spars: 28 mm · Head tube length: 190 mm · Fork bridge - center wheel axle: 385 mm · Thread length: 58 mm · Distance brake cam to wheel axle center-center: 85 mm

Clamps, nipples & set screws set 73 pcs.

Storage method: Plastic box · Manufacturer: Made in Germany · Storage box dimension [mm]: 18.5 x 11.0 x 1.8 cm · Material: Brass · Material: Steel · Surface: galvanized (blue) · Surface: nickel-plated · Surface: raw · Screw head: Hexagon · Number of components: 73 pcs · Drive: External hexagon · Drive: Knurled screw · Drive: Slot
