Piston ring 40 mm | Puch X30 Velux

GPO 15 mm carburetor tuning | Puch

Manufacturer: GPO · Material: Aluminum · Area of application: Tuning · Component group Carburetor: Carburetor complete · Nominal diameter: 15 mm · Carburetor type: SRE · Width: 50 mm · Choke control: Hand choke · Total length: 66 mm · Height: 95 mm · Nozzle thread: M3.5x0.6 (standard thread) · Ø fuel hose connection: 6 mm · Ø Inside entrance: 15 mm · Ø Internal connection: 20 mm · Ø Output inside: 15 mm · Ø Air filter connection: 20 mm · Mixed oil connection: No · Mounting type: Plug connection clamped · Vacuum connection: No · Nozzle block: 2.17 · Camouflaged: No · Nozzle size: 62 · Clamping screw torque (max.): 4 N/m

GPO fork lock | Puch

Ø rotating part: 12 mm · Manufacturer: GPO · Wide locking block: 4.1 mm · Locking block length: 15.3 mm · Material: Brass · Material: Spring steel · Material: Steel · Surface: blank · Ø outside: 12 mm · Width: 17 mm · Total length: 40.8 mm · Length of turned part: 25.6 mm · Ø Pin: 8 mm

Gas cable Ø 1.25 mm x 220 cm (cylindrical nipple) Bing

Ø nipple: 3 mm · Nipple length: 5 mm · Manufacturer: Made in Germany · Area of application: Standard · Material: Steel · Surface: galvanized (blue) · Number of components: 1 pcs · Ø Stranded wire: 1.25 mm · Nipple shape: Cylinder · Cable length: 2200 mm

Starter cable Ø 1.5 mm x 160 cm | Puch Maxi

Ø nipple: 8 mm · Nipple length: 12 mm · Manufacturer: Made in Germany · Area of application: Standard · Material: Steel · Surface: galvanized (blue) · Number of components: 1 pcs · Ø Stranded wire: 1.5 mm · Nipple shape: Barrel (transverse) · Cable length: 1600 mm

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom

Possible lever positions: open / closed / reserve · Thread type: MF12x1 (fine pitch thread) · Material lever: Metal · Filter type: Plastic net · Ø fuel hose connection: 6 mm · Installation direction: horizontal / horizontal · Outlet direction: below · Spare tube shape: curved · Reserve level: 70 mm · Mounting type: Union nut

swiing nozzle set M3.5 (54 - 64) Bing SRE, SRA, SRC, SRF

Manufacturer: swiing · Material: Brass · Component group Carburetor: Spraying · Carburetor type: SRA (1/11/31) Velux · Carburetor type: SRA (1/11/35) Velux · Carburetor type: SRC · Carburetor type: SRE · Carburetor type: SRF · Drive: Slot · Quantity: 6 pcs · Total length: 6 mm · Nozzle type: Main nozzle · Nozzle thread: M3.5x0.6 (standard thread) · Nozzle size: 54 · Nozzle size: 56 · Nozzle size: 58 · Nozzle size: 60 · Nozzle size: 62 · Nozzle size: 64

swiing® revival bellows Ø 23/30 x 100 mm | Puch

Manufacturer: swiing® revival parts · Material: Rubber · Ø inside: 23 mm · Ø outside: 35 mm · Ø outside: 45 mm · Total length: 103 mm · Color: black · Ø inside 2: 30 mm

Magura gas cable clamp / deco cable clamp Ø 5 x 6 mm

Manufacturer: Magura · Material: Brass · Material: Steel · Surface: nickel-plated · Thread type: M4x0.7 (standard thread) · Drive: Slot · Number of components: 2 pcs · Ø outside: 5 mm · Total length: 6 mm · Ø Cable bushing: 1.6 mm · Screw head: Lens head · Thread length: 4 mm

Fortune / Merrick 2.00-2.50 x 16/17" inner tube

Manufacturer: Fortune · Tire width [inch]: 2 - 2.5 " · Tire width [mm]: 50.8 - 63.5 · Width [inch]: 2 · Width [inch]: 2 1/4 · Width [inch]: 2 1/2 · Tire height [%]: 100 · Old designation: 20 x 2 · Old designation: 20 x 2.25 · Old designation: 20 x 2.5 · Old designation: 21 x 2 · Old designation: 21 x 2.25 · Old designation: 21 x 2.5 · Valve type: TR4 Auto valve · Wheel size [inch]: 16 - 17 " · Wheel size [inch]: 17 "

EBR standard fork chrome | Puch

Manufacturer: EWC · Material: Steel · Surface: chrome-plated · Adjustable: No · Spar end distance (center-center): 140 mm · Ø head tube inside: 22 mm · Ø outer head tube: 26 mm · Head tube length: 180 mm · Fork bridge - center wheel axle: 383 mm · Total length: 570 mm · Thread type: MF26x1 (fine pitch thread) · Distance brake cam to wheel axle center-center: 40 mm · Ø spars: 23 mm · Thread length: 57 mm · Color: Chrome
