Puch engine & gearbox

GPO clutch trigger | Puch E50

Manufacturer: GPO · Area of application: (Dis)assembly tool · Material: Steel · Surface: blackened

Ignition cover Standard | Puch

Height: 48 mm · Ø inside: 125 mm · Ø outside: 130 mm · Material: Steel · Surface: chrome-plated · Color: Chrome · Number of fixing points: 2 pcs

swiing® ingenious clutch springs reinforced (+20%) | Puch E50

Spring design: Pressure spring · Ø inside: 4.8 mm · Ø outside: 8.3 mm · Ø wire: 1.7 mm · Manufacturer: swiing® ingenious parts · Material: Spring steel · Area of application: Tuning · Surface: coated · Color: blue · Number of components: 3 pcs · Total length: 28 mm

Clutch lever | Puch E50

Area of application: Standard

Cover plate clutch torsion spring X30 Z50

Puch OEM number: 350.1.12.019.1

GPO oil filler plug gray | Puch Z50, ZA50

Ø outside: 16.4 mm · Manufacturer: GPO · Material: NBR · Color: gray · Ø mounting hole: 11 mm · Clamping diameter: 13 mm · Total length: 25 mm · Puch OEM number: 364.2.10.660.1

GPO oil filler plug black | Puch Z50, ZA50

Ø outside: 16.4 mm · Manufacturer: GPO · Material: NBR · Color: black · Ø mounting hole: 11 mm · Clamping diameter: 13 mm · Total length: 25 mm · Puch OEM number: 364.2.10.660.1

Rubber kickstarter original | Puch

Material: Rubber

GPO clutch plates (pair) | Puch X30

Manufacturer: GPO · Area of application: Standard · Number of slats: 2 pcs

GPO clutch 3-jaw aluminum | Puch E50

Ø inside: 12 mm · Ø inside: 14.6 mm · Ø outside: 93 mm · Manufacturer: GPO · Material: Aluminum · Area of application: Original · Area of application: Standard · Material: Steel · Material addition: Composite materials · Thickness: 20.9 mm · Recording type: Cone mounting · Number of jaws: 3 pcs · Number of springs: 3 pcs

swiing® revival gearbox cover gasket | Puch Maxi S LG2 ZA50 engine

Width: 133 mm · Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Thickness: 0.3 mm · Number of components: 1 pcs · Number of fixing points: 6 pcs · Total length: 175 mm

M6 sealing ring Fiber

Ø inside: 6.4 mm · Ø outside: 11.8 mm · Place of use: Carburetor · Material: Fiber · Place of use: Motor housing · Area of application: Standard · Surface: raw · Thickness: 1 mm · Puch OEM number: 24365

swiing® revival plain bearing clutch basket | Puch Z50

Ø inside: 15 mm · Ø outside: 17 mm · Manufacturer: swiing® revival parts · Material: special bearing bronze · Nominal diameter inside: 15 mm · Total height: 16.2 mm

swiing® revival thrust washer 12.5/18/2 gearbox | Puch Z50

Ø inside: 12.5 mm · Ø outside: 18 mm · Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Thickness: 2 mm

swiing® revival thrust washer 15/26/1 clutch | Puch Z50

Ø inside: 15 mm · Ø outside: 26 mm · Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Thickness: 1 mm

swiing® revival thrust washer 15/22/1.7 clutch | Puch E50, Z50

Ø inside: 15 mm · Ø outside: 22 mm · Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Thickness: 1.7 mm · Puch OEM number: 050.1213

swiing® revival pinion pulley | Puch Z50

Ø inside: 13.9 mm · Ø inside: 17.1 mm · Ø outside: 24.3 mm · Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Thickness: 3 mm · Nominal diameter (thread): 17 mm · Puch OEM number: 050.1.1319

Centering screw M22x1.5 plastic | Puch Z50

Thread type: MF22x1.5 (fine pitch thread) · Material: Plastic · Nut type: Hexagon nut · Drive: External hexagon · Puch OEM number: 329.1.12.133.1

swiing® ingenious torsion spring clutch lever reinforced +20% | Z50

Spring design: Torsion spring · Manufacturer: swiing® ingenious parts

Ignition rubber | Puch E50

Height: 11 mm · Width: 15 mm · Ø inside: 2.5 mm · Material: Rubber · Color: black · Ø inside 2: 5 mm · Waistband height: 2.5 mm · Total length: 30.3 mm · Total height: 15 mm

swiing® revival centering screw M22x1 galvanized | Puch Z50

Manufacturer: swiing® revival parts · Thread type: MF22x1 (fine pitch thread) · Material: Steel · Surface: galvanized (blue) · Nut type: Hexagon nut · Width across flats SW: 27 mm · Drive: External hexagon · Puch OEM number: 050.1.1233

Clutch pressure plate | Puch E50 Cat. (LG1)

Ø outside: 100 mm · Material: Steel · Thickness: 2 mm

Clutch release lever | Z50

Area of application: Standard

Wedge flywheel | Puch / Sachs / Zündapp

Width: 3 mm · Height: 3.8 mm · Material: Steel · Total length: 9.3 mm

Kickstart lever with rubber black | Puch

Width: 70 mm · Height: 70 mm · Material: Rubber · Material: Steel · Surface: varnished · Ø Shaft: 16 mm · Total length: 210 mm · Puch OEM number: 51.1.1337 · Puch OEM number: 349.2.13.640.1

GPO 3-jaw clutch (Ultra Light Version) | Puch E50

Manufacturer: GPO · Material: Aluminum · Material: Steel · Ø outside: 93.5 mm · Thickness: 21 mm · Recording type: Cone mounting · Number of jaws: 3 pcs · Number of springs: 3 pcs · Area of application: Tuning

Wedge clutch | Puch E50

Manufacturer: Puch · Material: Steel · Total length: 12.1 mm · Width: 3 mm · Height: 4.9 mm

Rito Crankshaft Racing | Puch E50

Manufacturer: Rito · Material: Steel · Cheek type: Full cheeks · Thread type: MF10x1 (fine pitch thread) · Crankshaft stroke: 43 mm · Ø piston pin (B): 12 mm · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 67 mm · Ø crank webs: 69.9 mm · Thread length: 11 mm · Thread length: 14 mm · Ø Connecting rod eye: 15 mm · Area of application: Racing · Area of application: Tuning · Ø Bearing seat (clutch side): 17 mm · Weight: 970 g · Ø Bearing seat (ignition side): 17 mm · Dimension needle bearing: 12 / 15 x 15 mm (axe 12) · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Length 2nd paragraph: 14.5 mm · Length 3rd paragraph: 25 mm · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Number of gears: 1 pcs

Circlip Ø 6 mm clutch shaft Puch E50

Fuse type: Inside · Manufacturer: Puch · Place of use: Clutch shaft · Nominal diameter: 6 mm · Puch OEM number: 900.4606

swiing® revival gearbox cover gasket (old model) | Puch Z50 engine

Width: 155 mm · Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Thickness: 0.35 mm · Number of components: 1 pcs · Number of fixing points: 8 pcs · Total length: 166 mm

swiing® revival gearbox cover gasket (new model) | Puch Z50 engine

Width: 120 mm · Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Thickness: 0.35 mm · Number of components: 1 pcs · Number of fixing points: 7 pcs · Total length: 170 mm

swiing® revival plain bearing clutch basket | Puch E50

Ø inside: 15 mm · Ø outside: 17 mm · Manufacturer: swiing® revival parts · Material: special bearing bronze · Nominal diameter inside: 15 mm · Total height: 21.75 mm

swiing® revival gasket set | Puch X30 Velux

Manufacturer: swiing® revival parts · Area of application: Standard · Number of components: 11 pcs · Ø outlet inside: 22 mm · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44

GPO gasket set | Puch E50

Manufacturer: GPO · Material: Aluminum · Material: Fiber · Material: Sealing carton · Material: Sealing paper · Area of application: Standard · Number of components: 7 pcs · Hole spacing inlet: 32 - 38 mm · Ø outlet inside: 19.9 mm · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44 · Decompressor: Yes

swiing® revival engine revision set (old model) | Puch E50

Manufacturer: NSK · Manufacturer: NTN · Manufacturer: swiing® revival parts · Area of application: Standard · Number of components: 7 pcs

swiing® revival engine revision set (new model) | Puch E50

Manufacturer: swiing® revival parts · Area of application: Tuning · Number of components: 7 pcs

Oil filler plug with sealing ring | Puch Maxi

Thread type: M10x1.5 (standard thread) · Material: Steel · Surface: galvanized (blue) · Number of components: 2 pcs · Drive: Slot · Screw head: Lens head · Ø External head: 14 mm · Total length: 14.6 mm · Thread length: 6 mm · Puch OEM number: 364.1.10.660.1

swiing® revival M8x12 oil drain plug & copper ring | Puch E50, Z50

Width across flats Screw: 13 mm · Manufacturer: swiing® revival parts · Thread type: M8x1.25 (standard thread) · Material: Copper · Material: Steel · Surface: galvanized (blue) · Color: silver · Drive: External hexagon · Drive: Slot · Total length: 18 mm · Screw head: Hexagon · Thread length: 12 mm · Puch OEM number: 901.1053

Starter cable Ø 1.5 mm x 160 cm | Puch Maxi

Ø Stranded wire: 1.5 mm · Nipple shape: Barrel (transverse) · Ø nipple: 8 mm · Manufacturer: Made in Germany · Area of application: Standard · Material: Steel · Surface: galvanized (blue) · Number of components: 1 pcs · Cable length: 1600 mm · Nipple length: 12 mm

swiing® revival gasket set Z50 engine | Puch X30 NS / NL

Manufacturer: swiing® revival parts · Material: Sealing paper · Area of application: Standard · Number of components: 10 pcs · Hole spacing inlet: 32 - 38 mm · Ø outlet inside: 22 mm · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44

Pedestal bearing shell | Puch

Height: 20 mm · Width: 46 mm · Material: Aluminum · Material: Steel · Surface: galvanized (blue) · Surface: raw · Color: silver · Mounting type: Screws · Number of fixing points: 3 pcs · Hole spacing: 41 mm · Total length: 70 mm

swiing® revival gasket cylinder base | Puch Kat

Manufacturer: swiing® revival parts · Place of use: Cylinder base · Material: Sealing paper · Thickness: 0.6 mm

GPO gasket cylinder base 0.35 mm original | Puch

Ø inside: 47 mm · Manufacturer: GPO · Place of use: Cylinder base · Material: Oiled paper · Area of application: Standard · Nominal diameter: 47 mm · Thickness: 0.3 mm · Hole pattern [mm]: 44 x 44 · Puch OEM number: 349.3.10.013.1

Puch inlet gasket original

Ø inside: 15 mm · Place of use: Admission · Area of application: Original · Material: Sealing paper · Thickness: 0.35 mm · Hole spacing inlet: 32.5 - 38 mm · Ø screw holder: 6.3 mm

GPO 38 mm gasket cylinder head 0.4 mm aluminum | Puch

Ø inside: 39 mm · Manufacturer: GPO · Material: Aluminum · Place of use: Cylinder head · Area of application: Standard · Nominal diameter: 39 mm · Thickness: 0.4 mm · Ø cylinder: 38 mm · Hole pattern [mm]: 44 x 44 · Ø screw holder: 7 mm · Puch OEM number: 349.3.10.013.1

Surflex pressure plate clutch | Puch E50

Ø outside: 94.5 mm · Ø outside: 100 mm · Manufacturer: Surflex · Area of application: Original · Material: Steel · Surface: galvanized (blue)

swiing® revival clutch spring 2-disc version | Puch Z50

Spring design: Pressure spring · Ø inside: 30.5 mm · Ø outside: 39 mm · Ø wire: 4 mm · Manufacturer: swiing® revival parts · Area of application: Original · Material: Spring steel · Area of application: Standard · Surface: raw · Color: gray · Number of components: 1 pcs · Total length: 19.5 mm

swiing® ingenious needle roller bearing 12/15/16.2 "Racing" silver cage

Width: 16.2 mm · Bearing cage: Silver cage · Ø inside: 12 mm · Ø outside: 15 mm · Manufacturer: swiing® ingenious parts · Bearing type: Needle roller and cage assembly · Dimension needle bearing: 12/15 x 16.2 · Tomos OEM number: 035548

Jasil crankshaft | Puch 3- & 4-speed models

Manufacturer: Jasil · Area of application: Standard · Total length of crankpin on clutch side: 73 mm · Number of gears: 3 pcs · Number of gears: 4 pcs

swiing® revival thrust washer 12.5/18/2.5 gearbox | Puch Z50

Ø inside: 12.5 mm · Ø outside: 18 mm · Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Thickness: 2.5 mm
