Lockable fuel filler neck suitable for your Piaggio Ciao moped / moped.
Ø outer: 50 mm
Ø spigot: 32 mm
Spigot length: 76 mm
Total length: 105 mm
Note: The O-ring is not highly resistant to mechanical influences and can therefore tear when pulled in and out. It is recommended to replace this with a sealing ring from the accessories.
Height | 105 mm |
Material | Plastic |
Color | black |
Fuel filler cap | Plug 33 mm |
Lockable | Yes |
Vented | Yes |
Ø External head | 54 mm |
Piaggio | Ciao - P, SC, PX, C24 |
