GPO 45 mm cylinder kit 12 mm KoBo | Tomos A35

Airsal 44 mm cylinder kit tuning 12 mm KoBo | Tomos A35

Manufacturer: Airsal · Material: Aluminum · Surface: sandblasted · Nominal diameter: 44 mm · Displacement: 65 ccm · Ø piston pin (B): 12 mm · Ø cylinder neck: 47.4 mm · Ø outlet inside: 22 mm · Hole spacing inlet: 31.5 mm · Hole spacing inlet: 36 mm · Hole spacing inlet: 39 mm · Inlet window: 29.5 x 37.5 mm · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 44 x 44 · Number of fixing points: 4 pcs · Outlet type: straight · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Area of application: Tuning · Decompressor: No · Camouflaged: No

Airsal 44 mm cylinder kit tuning 10 mm KoBo | Tomos A35

Manufacturer: Airsal · Material: Aluminum · Surface: sandblasted · Nominal diameter: 44 mm · Displacement: 65 ccm · Ø piston pin (B): 10 mm · Ø cylinder neck: 47.4 mm · Ø outlet inside: 22 mm · Hole spacing inlet: 31.5 mm · Hole spacing inlet: 36 mm · Hole spacing inlet: 39 mm · Inlet window: 29.5 x 37.5 mm · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 44 x 44 · Number of fixing points: 4 pcs · Outlet type: slanted · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Area of application: Tuning · Decompressor: No · Camouflaged: No

GPO gasket set 45 mm cylinder & diaphragm | Tomos A3, A35

Manufacturer: GPO · Number of components: 5 pcs · Material: Aluminum · Material: Composite materials · Material: Oiled paper · Ø cylinder: 45 mm · Hole pattern [mm]: 44 x 44 mm / 39 x 36/32 mm · Hole spacing outlet: 42 mm · Area of application: Tuning · Decompressor: Yes

GPO 44 mm cylinder kit tuning 12 mm KoBo | Tomos A35

Manufacturer: GPO · Material: Aluminum · Surface: sandblasted · Nominal diameter: 44 mm · Displacement: 65 ccm · Crankshaft stroke: 43 mm · Ø piston pin (B): 12 mm · Ø cylinder neck: 47.8 mm · Ø outlet inside: 22.8 mm · Hole spacing inlet: 36 mm · Hole spacing inlet: 39 mm · Inlet window: 35.5 x 29.5 mm · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 44 x 44 · Number of fixing points: 4 pcs · Outlet type: slanted · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Area of application: Tuning · Decompressor: No · Camouflaged: No

Parmakit 45 mm cylinder kit tuning 12 mm KoBo | Tomos A35

Manufacturer: Parmakit · Material: Aluminum · Surface: sandblasted · Nominal diameter: 45 mm · Displacement: 70 ccm · Crankshaft stroke: 43 mm · Ø piston pin (B): 12 mm · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 44 x 44 · Number of fixing points: 4 pcs · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Area of application: Tuning · Camouflaged: No

Piston 45 mm (12 mm KoBo) | Tomos A3 / A35

Nominal diameter: 45 mm · Ø outside piston (A): 44.94 mm · Ø piston pin (B): 12 mm · Compression height (C): 22 mm · Curvature (D): 4 mm · Total piston height (E): 49.55 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Weight piston kit: 91 g

45 mm cylinder head Racing (with O-ring & centering) | Tomos

Ø cylinder: 45 mm · Hole pattern [mm]: 44 x 44 · Number of fixing points: 4 pcs · Area of application: Racing

Chrome mirror

Thread type: M8x1.25 (standard thread) · Material: Steel · Test mark: none · Surface: chrome-plated · Color: Chrome · Ø mirror surface: 96 mm · Ø mirror rod: 7 mm · Clamping diameter: 22 mm · Mirror rod length: 230 mm · Thread size: M8 · Total length: 285 mm

TECNO exhaust 28 mm straight outlet chrome | Tomos

Manufacturer: TECNO · Material: Steel · Surface: chrome-plated · Color: Chrome · Mounting type: Welded lug · Number of fixing points: 1 pcs · Ø Flame tube outside: 28 mm · Exhaust type: Cigar · Flame tube attachment: Flange

Long bench seat | Tomos

Width: 180 mm · Manufacturer: Made in Portugal · Material: Imitation leather · Color: black · Lettering: Yes · Total length: 520 mm

TECNO Circuit Exhaust blank | Tomos A3

Manufacturer: TECNO · Material: Steel · Surface: varnished · Mounting type: Welded lug · Number of fixing points: 1 pcs · Ø Flame tube outside: 25 mm · Exhaust type: Snail · Flame tube attachment: Flange

GPO oil seal set | Tomos A35

Temperature resistance (min.): -30 - 100 °C · Shaft seal type: A DUO - With rubberized outer casing / two sealing lips. · Ø outside: 24 mm · Ø outside: 35 mm · Ø outside: 47 mm · Width: 7 mm · Manufacturer: GPO · Material: NBR · Ø inside: 16 mm · Ø inside: 17 mm · Ø inside: 35 mm

Intake manifold 19 mm PHBG aluminum welded | Tomos A35

Material: Aluminum · Surface: sandblasted · Ø inside: 19 mm · Ø External connection: 25 mm · Mounting type: Screws · Hole pattern [mm]: 39 x 32 · Number of fixing points: 4 pcs · Area of application: Tuning

Gearbox cover gasket | Tomos

Manufacturer: Tomos · Number of components: 1 pcs · Material: Sealing paper · Number of fixing points: 9 pcs · Tomos OEM number: 209083

GPO 14 mm intake manifold (camouflaged) | Tomos

Ø inside: 14.5 mm · Manufacturer: GPO · Material: Aluminum · Area of application: Tuning · Camouflaged: Yes · Ø External connection: 18 mm · Mounting type: Screws · Number of fixing points: 4 pcs
